Multiquip MVH408GV Reversible Plate Compactor

Multiquip MVH408GV Reversible Plate Compactor

Store / Compaction Equipment Sales / Vibratory Plate Compactors
$13,430.20
In stock
Product Details
Brand: Multiquip
12,365 lbs cf, Vanguard 400 Gas, 20" wide plate

Multiquip’s Mikasa Reversible Plate Compactors are the ideal high-production machines for efficient compaction of sand, gravel and cohesive soils.

  • Reliable Vanguard 400 engine.
  • Fold-out front cover for easy access to all maintenance points.
  • Hour/Tachometer to measure machine hour usage and engine RPM.
  • Cyclonic pre-cleaner to capture most airborne contaminants for engine protection and extended service life.
  • Heavy duty shock mounts to withstand harsh operating environment while reducing vibration to the operator and helping to extend component life.
  • Hydraulic controls enables operator to easily switch direction from forward to reverse while also allowing for spot compaction.
  • Rugged base plate manufactured from high strength steel for top performance and featuring open design for easy cleanup.
  • Steel frame protective guard with fully integrated cage protects the engine from loose debris or dirt while serving as a lifting bar for easy portability.
  • Low profile base plate lowers the center of gravity dramatically improving travel speed.
  • Extension plates can be added or removed to operating working width up to 6 inches.


Unit Specifications
Centrifugal Force 12365 lbf 55 kN
Exciter Speed 4400 VPM
Plate Size 20 x 35 in
500 x 900 mm
Plate Size
with Extensions		 26 x 35 in
650 x 900 mm
Max Forward Speed
Per Min.		 82 ft 25 m
Vanguard 160
Dimensions & Weights
Overall Length 62 in 1570 mm
Overall Width 26 in 650 mm
Overall Height 48 in 1210 mm
Operating Weight 836 lb 379 kg
Shipping Weight 836 lb 379 kg
